HSM-11 is a high-performance continuous zoom stereo microscope with wide zoom ratio (11:1) and long working distance (110mm) designed with Greenough optical system.
Product Description:
HSM-11 is a high-performance continuous zoom stereo microscope with wide zoom ratio (11:1) and long working distance (110mm) designed with Greenough optical system. It is the perfect choice for both low-magnification (0.6X) macroscopic observation and close-up observation with a clear high-magnification (6.6X) field of view.
The products can provide customized product packages equipped with LED lighting and digital cameras according to different requirements of scientific research, experiment, teaching or industrial inspection.
Technical Specifications of Stereo Microscope:
| Specifications | Paraeter |
| Model Type | HSM-11 |
| Optical System | Greenough |
| Magnification | 6-66X（Standard） |
| Zoom Radio | 11:01 |
| System Resolution | Horizontal：3 μm |
| Observation Tube | 45° Inclined binocular viewing tube, Interpupillary distance adjustment 55-75 mm |
| 45° Inclined trinocular viewing tube, Interpupillary distance adjustment 55-75 mm | |
| Eyepiece | High eye point WF10X, Φ23mm |
| Objective Lens | 0.6-6.6X Continuous zoom objective |
| Working Distance | 110 mm |
| Auxiliary Objective （Optional） | 0.5X, Magnification 3.0-33X, Working distance 165mm |
| 0.7X, Magnification 4.2-46.2X, Working distance 120mm | |
| 1.5X, Magnification 9.0-99X, Working distance 45mm | |
| 2 X, Magnification 12-132X, Working distance 30mm | |
| Table diameter | 100mm |
| Light Source （Intensity adjustable） | Upper Lighting, Ring LED 5W Side Lighting, LED 5W Under Lighting, LEDBacklight 5W |
| Camera Port | C Interface |
| Overall Size (WxLxH) | 380 X 260 X 450mm |
Circuit Board:
Industrial Manufacturing:
