The quantitative phase imaging module provides a research-grade inverted microscope with three-dimensional dynamic label-free quantitative imaging of optically thin samples
Product Description:
The quantitative phase imaging module provides a research-grade inverted microscope with three-dimensional dynamic label-free quantitative imaging of optically thin samples, and provides a relatively complete solution for life science research such as transparent biological cells, bacteria, and living tissue culture.
Technical Specifications of Quantitative Phase Imaging Module:
| Specifications | Paraeter |
| Model Type | Quantitative Phase Imaging Module |
| Camera | 5M Pixels Color CMOS Global shutter Pixel size: 3.45μm×3.45μm |
| Acquisition Rate | 2448×2048 @30fps |
| 1224×1024 @80fps | |
| Compatible Objectives | 20x0.4NA, Apo |
| 40x0.65NA, Apo | |
| 60x0.85NA, Apo | |
| Optical Resolution | Lateral Resolution: 800nm @20x0.4NA Apo |
| Lateral Resolution: 720nm @40x0.65NA、60x0.85NA Apo | |
| System Spatial Phase Sensitivity | 1 nm （Wide spectrum LED） |
| System Time Phase Sensitivity | 0.05nm （Wide spectrum LED） |
| Supply/Data Transformation port | USB3.0 |
| Data Format | Tiff bmp png / avi MPEG |
| Software | HR wDPM-V1.0 |
| Dimensions（mm） | Host length 240 Connecting pipe length106 Width 140 High150 |
